Wi‑Fi 7 (IEEE 802.11be) represents a major leap forward in capability, introducing:

• Channel widths up to 320 MHz

• 4K QAM modulation for increased data density

• Multi‑Link Operation (MLO), enabling simultaneous use of multiple frequency bands

• Theoretical speeds exceeding 40 Gbps

While actual performance will vary, enterprise‑grade Wi‑Fi 7 access points already require 10 Gbps uplinks — a challenge for older copper installations.

Access points that once operated at 1 GbE now demand:

• 2.5 GbE, 5 GbE, or 10 GbE uplinks

• Higher PoE power for advanced processing and internal cooling

• Consistent signal integrity at elevated frequencies

Without properly specified structured cabling, these new capabilities are limited. Poor cabling effectively throttles wireless performance, preventing networks from achieving their designed potential.

The backhaul — the wired connection linking access points to the core network — has become the critical point where performance is either enabled or lost.

Today’s wireless environments face three key challenges:

Wi‑Fi 7 access points can serve large device populations simultaneously, generating 5–10 Gbps of aggregated traffic per access point. High‑density venues like campuses, hospitals, and commercial buildings push this even further.

Collaboration tools, AR/VR platforms, and industrial automation all require low and consistent latency. Even small inefficiencies in cabling can add delay or packet loss, undermining the wireless experience.

Wi-Fi devices often require PoE++ (IEEE 802.3bt). Low-grade cables introduce resistance and heat, reducing voltage and endangering performance longevity.

DINTEK structured cabling systems are engineered for 10 GbE and PoE++ operation, ensuring consistent, safe, and efficient performance throughout the network lifecycle.

Supporting next‑generation wireless environments requires a cabling system designed for endurance, flexibility, and compliance with evolving standards.

• Category 6A cabling is the DINTEK‑recommended baseline for Wi‑Fi 7.

• Supports 10GBASE‑T up to 100 metres.

• Provides superior alien crosstalk suppression and reliability.

• Optimised to handle high‑power PoE without performance degradation.

While Category 6 can support multi‑gigabit speeds over short runs, it leaves no room for expansion. Category 6A delivers the stability and headroom required for enterprise‑grade networks.

• Specify singlemode or OM4 multimode fibre for links between distribution rooms and core switches.

• Fibre provides scalability to 25G, 40G, and 100G, meeting future bandwidth demands.

• Offers inherent immunity to electromagnetic interference for improved reliability.

• Zone‑based architectures enable flexible access point positioning.

• Consolidation points should be rated for 10 GbE and PoE performance.

• DINTEK systems are factory‑tested and certified end‑to‑end for guaranteed channel performance.

• Use patch cords that match or exceed the permanent link’s category.

• Substandard cords are a common cause of performance loss.

• DINTEK connectivity solutions ensure consistent electrical performance and mechanical durability across every connection.

Wireless standards evolve every few years, but structured cabling typically remains in service for 10–15 years or more. Smart cabling decisions made today will support multiple generations of wireless technology.

A robust structured cabling system delivers:

• Headroom for future wireless speeds

• Support for higher PoE power levels

• Lower downtime and maintenance costs

• A reduced total cost of ownership

In this light, cabling is not a cost to be minimised — it is a strategic investment in network performance, reliability, and scalability.
